LocationService – Documentation

Overview

LocationService is an Android foreground service designed to continuously track the user’s location, handle GPS and internet outages, detect mock locations, and send location data to a server using Socket.IO. The service is resilient to process death and network issues and includes a periodic watchdog via WorkManager to restart itself if needed.

Components

1. Service Initialization

override fun onCreate() {
    super.onCreate()
    log("Service onCreate called")
    setupSocket()
    acquireWakeLock()
    registerReceivers()
    schedulePeriodicWork()
}

• Called when the service is first created.
• Initializes the socket connection, acquires a partial wake lock (to keep CPU on), registers receivers (if any), and schedules periodic monitoring via WorkManager.

private fun setupSocket() {
    try {
        socket = IO.socket("https://route.getfieldy.com")
        socket.connect()
    } catch (e: URISyntaxException) {
        log("Socket error: ${e.message}")
    }
}

• Initializes and connects the Socket.IO instance to the backend server.

2. Service Lifecycle

@RequiresApi(Build.VERSION_CODES.O)
override fun onStartCommand(intent: Intent?, flags: Int, startId: Int): Int {
    val action = intent?.action
    log("onStartCommand called. Intent action: $action")

    if (action == null && !isRunning) {
        startTracking()
    } else {
        when (action) {
            ACTION_START -> startTracking()
            ACTION_STOP -> {
                prefs.edit().putBoolean("IS_RUNNING", false).apply()
                stopTracking()
            }
        }
    }
    return START_STICKY
}

• Handles service start and stop commands.
• Ensures the service continues to run (START_STICKY) even if the system kills it.

3. Location Tracking Setup

private fun startTracking() {
    isRunning = true
    prefs.edit().putBoolean("IS_RUNNING", true).apply()

• Marks the tracking as active in SharedPreferences.

    val locationDataString = prefs.getString("LOCDATA", "_")
    if (locationDataString != "_") {
        val locData = JSONObject(locationDataString ?: "{}")
        userName = locData.getString("name")
        userImageUrl = locData.getString("image")
        tenantId = locData.getString("tenant")
        technicianId = locData.getString("technician")
        metaDataId = locData.getString("metaId")
        metaDataType = locData.getString("metaType")
    }

• Loads stored user/technician and tracking metadata from preferences.

    setupNotification()
    locationClient = LocationServices.getFusedLocationProviderClient(this)

• Builds the notification and initializes the FusedLocationProviderClient.

    val locationRequest = LocationRequest.Builder(Priority.PRIORITY_HIGH_ACCURACY, 5000L)
        .setMinUpdateIntervalMillis(5000L)
        .setWaitForAccurateLocation(true)
        .setGranularity(Granularity.GRANULARITY_FINE)
        .setMinUpdateDistanceMeters(5f)
        .build()

• Configures a high-accuracy location request with a 5-second interval and 5-meter minimum movement.

    locationCallback = object : LocationCallback() {
        override fun onLocationResult(result: LocationResult) {
            result.locations.forEach { location ->
                processLocation(location, result)
            }
        }
    }

• Defines how to handle new location updates.

    locationClient.requestLocationUpdates(
        locationRequest,
        locationCallback,
        Looper.getMainLooper()
    )
}

• Starts receiving location updates from the fused location provider.

4. Location Handling and Emission via Socket

private fun processLocation(location: Location, result: LocationResult) {
    val isMockLocation = if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.S) {
        location.isMock
    } else {
        location.isFromMockProvider
    }

• Determines if the current location is mocked (fake GPS).

    batteryPercentage = getBatteryPercentage()

• Retrieves the current device battery percentage.

    val message = when {
        batteryPercentage < 20 -> "⚠️ Low battery: $batteryPercentage%"
        isMockLocation -> "⚠️ Mock location detected."
        else -> "Tracking location... ${location.latitude}, ${location.longitude}"
    }

• Decides what message to show based on mock/battery status.

    notification = buildNotification(message)
    notificationManager.notify(1, notification)

• Updates the foreground notification dynamically.

    prepareData(location, result)
}

• Passes data to be structured and sent.

private fun prepareData(location: Location, result: LocationResult) {
    val isMockLocation = if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.S) location.isMock else location.isFromMockProvider
    val isInternetAvailable = isInternetAvailable()

• Checks mock location and current network availability.

    val locationData = buildLocationData(
        location.latitude,
        location.longitude,
        0.0,
        batteryPercentage,
        event = if (isMockLocation) "location_mocked"
                else if (isGPSoutage) "gps_outage"
                else if (!isInternetAvailable) "internet_disconnected"
                else if (metaDataType == "availability_on_traveling") "availability_on_traveling"
                else "traveling",
        mocked = isMockLocation,
        accuracy = location.accuracy,
        speed = location.speed,
        bearingDiff = location.bearingAccuracyDegrees.toString(),
        locationResult = result
    )

• Builds a JSON object with the current location context.

    if (isInternetAvailable) {
        sendToSocket(locationData)
        prefs.getString("OFFLINE_DATA", null)?.let {
            sendToSocket(JSONObject(it))
            val recoveryData = JSONObject(locationData.toString()).apply {
                put("event", "internet_resumed")
            }
            sendToSocket(recoveryData)
            prefs.edit().remove("OFFLINE_DATA").apply()
        }
    } else {
        prefs.edit().putString("OFFLINE_DATA", locationData.toString()).apply()
    }
}

• Sends live data via socket if online, or stores it offline if not.
• If offline data exists when internet resumes, it also gets sent.

5. Send to Server via Socket.IO

private fun sendToSocket(locationData: JSONObject) {
    if (!socket.connected()) {
        try {
            socket.connect()
        } catch (e: Exception) {
            log("Socket reconnect failed: ${e.message}")
        }
    }
    when (metaDataType) {
        "travel_history_full_day_tracking" -> socket.emit("travel_history_full_day_tracking", locationData)
        "availability_on_traveling" -> socket.emit("current_location", locationData)
        else -> socket.emit("travel_history", locationData)
    }
}

• Reconnects socket if disconnected.
• Emits different event types depending on the tracking mode (metaDataType).

Monitoring & Utilities

6. Background Watchdog

class ServiceMonitorWorker(context: Context, workerParams: WorkerParameters) : Worker(context, workerParams) {
    override fun doWork(): Result {
        val prefs = applicationContext.getSharedPreferences("FlutterSharedPreferences", Context.MODE_PRIVATE)
        if (!prefs.getBoolean("IS_RUNNING", false)) {
            val intent = Intent(applicationContext, LocationServiceV2::class.java).apply {
                action = LocationServiceV2.ACTION_START
            }
            ContextCompat.startForegroundService(applicationContext, intent)
        }
        return Result.success()
    }
}

• Periodic WorkManager worker that checks if the service is still running.
• If stopped, it restarts the service using ContextCompat.startForegroundService.

Conclusion

This version of LocationService uses Socket.IO for real-time transmission of location data, suitable for applications that need low-latency live tracking, such as fieldwork or logistics. Socket reconnection and offline buffer handling are included to ensure robustness.
